| • Generator set specification |
600 KVA |
| Model |
C600D5P |
| Duty |
Prime |
| Power Rating kVA / kWe |
600 /480 . |
| No of Phases |
3 |
| Output Voltage (V) |
415 |
| Power Factor (ɸ) |
0.8 ( Lagging) |
| Frequency (Hz) and RPM |
50 Hz, 1500 RPM |
| • Engine Specification |
|
| Make |
Cummins |
| Model |
QSK19-G6 |
| MoEF Certified Power (bhp) |
782 |
| Cooling type |
Liquied Cooled |
| Type of Aspiration |
TurboCharged , Charged Aircooled |
| No. of cylinders |
6 -Inline |
| Bore (mm) x Stroke (mm) |
159 X 159 |
| Starting system |
24V DC Electrical |
| Lube oil specification |
CH4+ 15W40 |
| • Alternator Specification |
|
| Make |
Stamford (CGT) |
| Alternator frame |
HCI544E |
| Enclosure |
IP23 |
| Voltage regulation (Max.) |
± 1 % |
| Class of Insulation |
H Class |
| Enclosed Genset Dimensions ( Length x Width x Height) in mm |
6500 X 2010 X 2800 |
| Wet Weight in KG |
9029 |
| Standard Fuel Tank Capacity ( in Ltr) |
750 |
